Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve

Certification
Good quality Butterfly valve for sales
I'm Online Chat Now

Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve

China Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve supplier
Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve supplier Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve supplier Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve supplier Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve supplier Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve supplier Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve supplier Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve supplier

Large Image :  Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve

Product Details:

Place of Origin: China
Brand Name: XinYi
Certification: ISO9001
Model Number: XYEO

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD420-450/SET
Packaging Details: Wooden Box
Delivery Time: Within 1-3 days after receiving your payment
Payment Terms: T/T
Supply Ability: 10000/SET/YEAR
Contact Now
Detailed Product Description
Operating Power: Standard Types:AC230V 50/60HZ Special Types: AC110V 24V
Connection Method: Flange Actuating Modes: P、 PI、 PID.driven By Servo Motor Also Can Operated By 0/4-20mA0/2-10VDC
Materials: SUS316, ,304 Accessories: Locator, .solenoid Valve Limit Switch
Applicable Mediums: Applicable Mediumall Kinds Of Mediums Which Contain No Obvious Particles Temperature Range: -30~-350~C
Pressure(Mpa): PN16 Sealing Types: Bellows Seal Type Plus Safety Gland Plus Graphite-contained PTFE Sealing
Torque Of The Actuator: 2000N、4000N、9000N、10000N Materials Of Valve Seat Ring/disc: 1.SUS316L Hard Alloy 2.PTFE Containing Graphite

Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve

The Valve offers numerous benefits over other control valves including long life stem seals proven millions of times over, flexible changeable trims offering multiple Kvs values per body size, precise and durable operation (even at high differential pressures) thanks to the vibration reducing shaft guiding, easy handling, the small footprint, rotatable upper part and reduced weight when compared with other control valves.

Suitable for non-critical complex control tasks uses in applications such as industrial complexes, plant construction and process technology installations for mediums such as cooling water, cooling brine, warm water, hot water and steam.

Offered as standard in the trim with Cast Iron Body, Stainless Steel Trim and the Spring-Loaded PTFE V-Ring unit complete with electric actuator with integrated positioner unit. Options available upon request include different trim materials, parabolic plugs with PTFE seats, miniature Kvs values, increased tightness on seats i.e. Class IV leakage rate.

If you are not sure of the size, you require for your process please do not hesitate to get in contact with our Technical Sales team who will be able to size the correct valve for your process.

Key Features:

  • Flanged Connection
  • Cast Iron Body & Stainless Steel Trim
  • Spring Loaded PTFE V-Ring Unit
  • Electric Actuator (90-264V AC 47-63Hz), 0-10V or 4-20mA Input
  • Up to -10 to +220°C Temperature Rated
  • DN15 to DN100, Kvs from 1 to 100
  • 50:1 Rangeability

Product Overviews

Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust ValveManufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve

Pneumatic Actuator
Body type: straight through casting globe type
Spool type: multi-layer choke spool
Nominal size: DN20~200 NPS 3/4 inch~ 8 inch
Nominal pressure: PN160 ~ 420 CLASS 900LB ~2500LB
Connection: flange: flange: FF,RF,MF,RTJ
  Welding: SW,BW
Bonnet type: standard type(-5℃~230℃),
Radiator type: (-45℃~higher than 230℃ occasion),
Low temperature extended type(-196℃~ -45℃)
Packing: V type PFTE packing, flex. graphite packing, etc.
Gasket: Metal graphite packing
Actuator: pneumatic: multi-spring diaphragm actuator, piston type actuator.
electric: 3810L series smart actuator, PSL series actuator.
Surface painting:

Green color, acrylic acid polyurthene ceramic paint.

Workshop



Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust ValveManufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve

Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve

Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust ValveManufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust ValveManufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve

FAQ



Q1. How to place the order?
A1: You can send us email or inquiry at alibaba directly.



Q2: Can you provide the free samples?
A2:Yes, the free samples is available. You just need to pay the freight cost.



Q3: Can I have my own customized product?
A3: Yes, your customized requirements for color, size, package, mark, etc.



Q4. Do you test all your goods before delivery?
A4: Yes, we have 100% test before delivery.



Q5: How long is your delivery time?
A5: Generally it is 10-20 days if the goods are in stock. Customized goods need to negotiate delivery.

Manufacturer 2 inch Carbon Steel Multi-Turn Electric Actuator Vertical movement Steam Globe adjust Valve
