Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection

Certification
Good quality Butterfly valve for sales
I'm Online Chat Now

Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection

China Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection supplier
Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection supplier Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection supplier Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection supplier Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection supplier Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection supplier Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection supplier Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection supplier Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection supplier Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection supplier Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection supplier Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection supplier

Large Image :  Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection

Product Details:

Place of Origin: China
Brand Name: XinYi
Certification: ce
Model Number: XYTA

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD39-170/SET
Packaging Details: Wooden Box
Delivery Time: Within 1-3 days after receiving your payment
Payment Terms: T/T
Supply Ability: 10000/SET/YEAR
Contact Now
Detailed Product Description
Nominal Pressure: 1.6Mpa Temperature Range: -50~-250C
Connection Method: Thread Actuating Modes: Pneumatic.manual(lock Available)
Materials: SUS316, ,304 Accessories: Locator, .solenoid Valve Limit Switch
Applicable Mediums: Water, Steam, Gas,oil Stuffing: PTFE+Flexible Graphite
Payment: T/T

Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection

Plastic Pneumatic cylinder ss316 pn25 Angle Seat Valve Thread Connection

Technical Data:

Fluid Pressure : Max×1.6MPa(232psi)

Control Pressure:0.3-0.8MPa(43.5-116psi)

Control Fluid:Neutral gas,Air

Actuator Size:27mm,32mm,40mm,50mm,63mm,80mm,100mm,125mm

Applicable Fluid:Water,Alcohol,Oil,Dye,Steam,Neutral gas or liquid,Organic solvent,Acid and lye

Fluid temperature:-10ºC-+180ºC,25ºC-+220ºC

Ambient temperature:-10ºC-+80ºC

Control Type:Normally closed,Normally open,Double acting

Connection: Threaded(BSP.BSPT,NPT),Welded, Flanged, Tri-clamp

Main Materials :

Body Material:CF8M(SS316),CF8(SS304)

Seals Material:PTFE

Actuator Material:CF8 (SS304)

Applications:

Beer& Drink Filling Machinery

Textile printing& Dyeing
Gas industry
Pharmacy& Medical Equipment
Chemical industry
Disinfection
Frothing Equipment
Water/sewage Disposal

Advantages:

1.Large Flux, low Resistance, No Water-hammer Y-type Shape Enlarged The Flowing Section, which Could Raise The Flux By 30% And Make Flow More Smooth
2.Super Long Life.
3.Which Help The Stem Adjust And Lubricate Itself Automatically.
4.The Cylinder Material is Stainless Steel.Lubricating Automatically,360 Rolling Freely.


Product Overviews

Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection

Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection

Pneumatic Actuator



Product Name Angle Valve
Applicable Medium Water, Gas, Oil, etc
Working Pressure 1.6 MPa
Body WCB
Valve Stem 304,316, 2Cr13,etc
Seal Material PTFE+Flexible Graphite
Working Temperature ≤250℃
Packing Details Usually Bubble Pack For Each Valve Within Carton Box Or Plywood Case, Or Special Packaging Upon Customer Requirements



Workshop

Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread ConnectionPlastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection

Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection

Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread ConnectionPlastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection

FAQ



FAQ
Q1. How to place the order?
A1: You can send us email or inquiry at Website directly.

Q2: Can you provide the free samples?
A2:Yes, the free samples is available. You just need to pay the freight cost.

Q3: Can I have my own customized product?
A3: Yes, your customized requirements for color, size, package, mark, etc.

Q4. Do you test all your goods before delivery?
A4: Yes, we have 100% test before delivery.

Q5: How long is your delivery time?
A5: Generally it is 10-20 days if the goods are in stock. Customized goods need to negotiate delivery.

Plastic Pneumatic Cylinder SS316 Pn25 Angle Seat Valve Thread Connection
